Nominal Impedance (Z) 4 ohms
DC Resistance (Re) ]] 3.2 ohms
Resonance Frequency (Fs) 30.7061 Hz
Piston Area (Sd) 0.0511 m2
Force Factor (BL) 12.4924 T.m
Mechanical Q Factor (Qms) 3.7494
Electrical Q Factor (Qes) 0.5764
Total Q Factor (Qts) 0.4996
Sensitivity 1W/M (SPL) 87.3024
Mechanical Comp (Cms) 0.1844 mm/N
Moving Mass (Mms) 145.7101 g
Linear Excursion (Xmax) 9 mm
Volume Acoustic Comp (Vas) 67.1494 Ltr/2.371348 cu ft
Reference Efficiency (NO.) 0.32% RMS
Power (Pe) 400 Watts
Frequency Response 20-250 Hz
Voice Coil Diameter 2.5 in/63.5 mm
Displacement 0.0619 cu ft/1.752 Ltr
