Nominal Impedance (Z) 4 ohms
DC Resistance (Re) ]] 3.2 ohms
Resonance Frequency (Fs) 41.2638 Hz
Piston Area (Sd) 0.0314 m2
Force Factor (BL) 13.6742 T.m
Mechanical Q Factor (Qms) 4.83
Electrical Q Factor (Qes) 0.6576
Total Q Factor (Qts) 0.5788
Sensitivity 1W/M (SPL) 83.7199
Mechanical Comp (Cms) 0.1004 mm/N
Moving Mass (Mms) 148.1991 g
Linear Excursion (Xmax) . 14 mm
Volume Acoustic Comp (Vas) 13.8342 Ltr/ 0.4885 Cu ft
Reference Efficiency (NO.) 0.1419% RMS
Power (Pe) 500 Watts
Frequency Response 20-200 Hz
Voice Coil Diameter 2.5 in/63.5 mm
Displacement 0.0626 cu ft/ 1.771 Ltr
